Tenko 46T: Schematics and user manual
I made a scan of the user manual, schematics included, of the Tenko 46T AM 27MHz transceiver. Also some pictures and how the crystals are mounted in my model.
- Bijlagen
-
Tenko46T User manual.pdf- Tenko 46T user manual and schematics
- (3.01 MiB) 2079 keer gedownload
-
- Crystals_Tenko46T.txt
- Crystal arrangement
- (249 Bytes) 1615 keer gedownload
-
tenko46t.zip- All the information in one ZIP file
- (5.24 MiB) 1871 keer gedownload
